Server LENOVO ThinkSystem SR650 (2x Xeon 8260M, 12x64GB, 4x1.92TB SSD, 5x1.8TB SAS)

Server LENOVO ThinkSystem SR650 (2x Xeon 8260M, 12x64GB, 4x1.92TB SSD, 5x1.8TB SAS)
2x Intel Xeon Platinum 8260M 24C 165W 2.4Ghz Processor
12 xThinkSystem 64GB TruDDR4 2933MHz (2Rx4
1.2V) RDIMM
5 x ThinkSystem 2.5" 1.8TB 10K SAS 12GB Hot Swap 512e HDD
Rackmount (4U)
Unit Utama
Spesifikasi
#2 Processor Onboard Intel Xeon Platinum 8260M Processor (24 cores, 2.40 GHz, 35.75M Cache)
Power Supply Type 2x 1600W
#1 Controller RAID 530-16i PCIe 12Gb Adapter
#1 Processor Onboard Intel Xeon Platinum 8260M Processor (24 cores, 2.40 GHz, 35.75M Cache)
Standard Memory 12x 64GB TruDDR4 2933MHz
Networking ThinkSystem 10Gb 2-Port SFP+ LOM
Others
ThinkSystem SR650 2.5" Chassis With 8, 16 or 24 bays
2x ThinkSystem 2U/Twr 2.5" SATA/SAS 8-Bay Backplane
Select Storage device - no configured RAID Required
ThinkSystem RAID 530-16i 4GB Flash PCIe 12Gb Adapter
4 x ThinkSystem 2.5" 5200 1.92TB Entry SATA 6GB Hot Swap SSD
ThinkSystem M.2 with Mirroring Enablement Kit
2 x ThinkSystem M.2 32GB SATA 6Gbps Non-hot swap SSD
ThinkSystem 2U x8/x8/x8 PCIe FH Riser 1
Qlogic 16Gb Enhanced Gen5 FC Dual-Port HBA
ThinkSystem Broadcom 5719 1GbE RJ45 4-Port PCIe Ethernet Adapter
2x SFP+ SR Transceiver
ThinkSystem Broadcom 57416 10GBASE-T 2-Port PCIe PCIe Adapter
2x 2.8m, 13A/100-250V, C13 to C14 Jumper Cord
ThinkSystem Xclarity Controller Standard to Enterprise Upgrade
ThinkSystem Toolless Slide Rail
ThinkSystem 2U left EIA Latch Standard
Feature Enable TPM 1.2
ThinkSystem SR650 Refresh MB
MS First 2U 8x2.5" HDD BP Cable Kit
MS 2nd 2U 8x2.5" Cable Kit
ThinkSystem 8x1 2.5" HDD Filler
3x ThinkSystem 1x1 2.5" HDD Filler
ThinkSystem 4x1 2.5" HDD Filler
XCC Network Access Label
2x ThinkSystem 4R CPU HS Clip
2x Lenovo ThinkSystem 2U MS CPU Performance Heatsink
ThinkSystem SR650 6038 Fan Module
Companion Part For Xclarity Controller Standart to Enterprise Upgrade in Factory
ThinkSystem common intel label
12x Lenovo ThinkSystem Memory Dummy
ThinkSystem Small Lenovo Label For 24x2.5"/12x3.5"/10x2.5"
ThinkSystem Response Time Service Label LI
ThinkSystem EAI Plate with LENOVO logo
ThinkSystem SR650 Model number Label
ThinkSystem 1600W RDN PSU Caution Label
Lenovo ThinkSystem 2U 3FH Riser Bracket
Lenovo ThinkSystem 2U 2FH Riser Dummy
4x Lenovo ThinkSystem M3.5" Screw for EIA
2x ThinkSystem M3.5" Screw for Riser 2x2pcs and Planar 5pcs
Notice for Advanced format 512E Hard Disk Drives
ThinkSystem Package dor SR650
2u Bracket fot ThinkSystem RAID 530-16i PCIe 12Gb Adapter
ThinkSystem SR650 WW LENOVO LPK
ThinkSystem SR650 Agency label Lenovo, No CCC
ThinkSystem 12-15 sequence label for 24x2.5" Chassis
ThinkSytem 4-7 sequence label for 2U 2.5"
Feature Enable TPM on MB
Configuration ID 01
Configuration Instruction
ThinkSystem RAID 530-16i PCIe 12Gb Adapter
Controller 01
Configuration ID01
Essential Service - 3Yr 24X7 4Hr Response + yourDrive Yourdata
Chassis Form Factor 4U Rackmount Chassis
Processor Type Intel Xeon Processor
Standard Warranty 3 Years Warranty
#1 Hard Drive 5x 1.8TB 10K SAS 12GB Hot Swap 512e HDD
Platform Quad CPU Rackmount Server
